••Rated charging power: 3.7, 7.4, 11 or 22.1 kW
••T2 socket outlet (with or without shutter) or attached cable
(with T1 or T2 connector)
••Heavy duty socket outlet with silver plated contacts avoiding overheating
Robustness
••Highly robust to mechanical impact: IK10
••Suitable for outdoor use: IP54
Easy to use
••”Plug and charge”
••One-touch stop/restart
••Attached cable rolled up around the Wallbox
••1 or 2 charging stations on the same pole
Selectable energy management function
••Delayed start allowing off-peak hours charging only
••Temporary current limitation (from 16 A to 10 A or from 32 A to 16 A)
protecting building users from blackouts.
Application
Wallbox are recommended for homes, as well as tougher environments (condominium, corporate car park,
hotel, etc.), because of their weatherproof and robust design.
Mechanical and environmental characteristics
••Ingress protection code: IP54
••Impact protection code: IK10
••Operating temperature: -30°C to +50°C
••Storage temperature: -40°C to +80°C
••Attached cable length: 4 m
••Energy management: deferred charging start or charging current
limitation (16 A to 10 A, 32 A to 16 A)
Charging access
••Free access
••By key lock, for socket outlet insertion and locking
