Benefits · Designed for 3-phase motor applications rated maximum 30 HP at 575 Vac · Current rating of contactor ranges from 9-40A · Circuit Breaker maximum current rating ranges from 15–95A · Available in both reversing and non-reversing versions
|
Maximum power AC3 duty(K W) |
Rated current (A) |
Type of Contactor |
Code Number |
Suitable Thermal Relay(A) |
|||||
|
220V 230V |
380V400V |
440V |
500V |
660V 690V |
|
|
|
|
|
|
2.2 |
4 |
4 |
5.5 |
5.5 |
9 |
LC1D09 |
LE1D09 |
LR2D1314 |
LRD14 |
|
3 |
5.5 |
5.5 |
7.5 |
7.5 |
12 |
LC1D12 |
LE1D12 |
LR2D1316 |
LRD16 |
|
4 |
7.5 |
9 |
10 |
10 |
18 |
LC1D18 |
LE1D18 |
LR2D1321 |
LRD21 |
|
5.5 |
11 |
11 |
15 |
15 |
25 |
LC1D25 |
LE1D25 |
LR2D1322 |
LRD22 |
|
7.5 |
15 |
15 |
18.5 |
18.5 |
32 |
LC1D32 |
LE1D32 |
LR2D2353 |
LRD23 |
|
11 |
18.5 |
22 |
22 |
30 |
40 |
LC1D40 |
LE1D40 |
LR2D3355 |
LRD35 |
|
15 |
22 |
30 |
30 |
33 |
50 |
LC1D50 |
LE1D50 |
LR2D3359 |
LRD40 |
|
18.5 |
30 |
37 |
37 |
37 |
65 |
LC1D65 |
LE1D65 |
LR2D3361 |
LRD3361 |
|
22 |
37 |
45 |
55 |
45 |
80 |
LC1D80 |
LE1D80 |
LR2D3363 |
LRD363 |
|
25 |
45 |
45 |
55 |
45 |
95 |
LC1D95 |
LE1D95 |
LR2D3365 |
LRD365 |
|
Enclosure |
LE-D09 and D12 |
Double insulated, protected to IP42 or IP65 |
|
|
LE-D18 and D25 |
Double insulated, protected to IP42 or IP65 |
|
|
LE-D32…D25 |
Matel, IP 55 to IP 59 |
|
Control 2 pushbuttons mounted on enclosure cover |
LE-D09…D95 |
1 green Start Button “1″, 1 red Stop/Reset button “O” |
|
Connections |
LE-D09…D95 |
Pre-wired power and contorl circuit connections |
|
Standard control circuit voltages |
|
|
|
Voltages |
24 48 110 220 230 240 380 400 415 440 |
|
|
50/60Hz |
B7 E7 F7 M7 P7 U7 Q7 V7 N7 R7 |
|
